Bộ chuyển đổi DeviceNet Slave sang DCON Master kết nối RS-232/RS-485 ICP DAS I-7241D-G CR

DeviceNet Slave to DCON Master Gateway

Tính năng

Bộ chuyển đổi DeviceNet Slave sang DCON Master kết nối RS-232/RS-485 ICP DAS I-7241D-G CR

• Group two only server DeviceNet subscriber
• Support Predefined Master/slave Connection Set
• Dynamic Assembly Objects Mapping
• Support Offline Connection Set, Device Heartbeat message and Device Shutdown message
• Provide Assembly object
• Dynamic Product EDS File
• I/O operating modes: Polling, Bit-Strobe, Change of State/Cyclic
• Support max 15 I-7K/I-87K IO modules
• Explicit & I/O length: 240 bytes max.
• Provide friendly Utility to configure
• Baud Rate: 125Kb, 250Kb, 500Kb
• On-line change baud rate and MAC ID
• 7-segmemt LED to show operation mode, MAC ID, baud rate and error code

Chia sẻ:
Model: I-7241D-G CR
Views: 566

Bộ chuyển đổi DeviceNet Slave sang DCON Master kết nối RS-232/RS-485 ICP DAS I-7241D-G CR

The I-7241D is the communication gateway between DeviceNet and DCON protocols. It is a DeviceNet slave device in the DeviceNet network, which functions as a “Group 2 Only Slave” device, and supports “Predefined Master/slave Connection Set”. In the DCON network, the I-7241D is a DCON master and can access the data of the I-7000 or I-87k series modules. The utility software is given to configure the device parameters and build EDS file for the DeviceNet slave device. Through the I-7241D, the DeviceNet master can quickly integrate the I-7000 and I-87K series modules into the DeviceNet network.

  • Control System
  • Building Automation
  • Factory Automation
  • Distributed data acquisition
CPU Module
CPU 80188, 40 MHz or compatible
EEPROM 16 KB
Watchdog Timer Yes
LED Indicators
Status 1 x Power
2 x DeviceNet status
COM Ports
Ports 1 x RS-232 (Utility Port)
1 x RS-485 (DCON)
Baud Rate 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
Protocol RS-485 (DCON)
Parity None, Even, Odd
Data Bit 7, 8
Stop Bit 1, 2
DeviceNet
Controller NXP SJA1000T with 16 MHz clock
Ports 1
Connection Supported 1 connection for Explicit Messaging
1 connection for Polled I/O
1 connection for Bit-Strobe I/O
1 connection for COS/Cyclic I/O
Isolation 1000 VDC for DC-to-DC, 2500 Vrms for photo-couple
Terminal Resistor Jumper for 120 Ω terminal resistor
Specification Volume I, Release 2.0 & Volume II, Release 2.0
Shutdown Message Yes
Heartbeat Message Yes
Subscribe Group 2 Only Server
Power
Input Range +10 VDC ~ +30 VDC
Consumption 3W
Mechanical
Dimensions (mm) 72 x 122 x 33 (W x L x H)
Installation DIN-Rail
Environment
Operating Temperature -25 ~ +75 ℃
Storage Temperature -30 ~ +80 ℃
Humidity 10 ~ 90% RH, Non-condensing
I-7241D-G     CR DeviceNet Slave / DCON Master Gateway (RoHS)
